Other information:
Circuit Diagram
Harness Connector
Pin No.
Description
1
V_BAT_ECU
2
IG_ON
3
CAN High
4
CAN_Low
5
...
Inspection
1.
With the power seat switch in each position, make sure that continuity
exists between the terminals below. If continuity is not as specified,
replace the power seat switch.
Removal
1.
...
